Digital Insulation Tester

Description

• Model No : TA319
• Brand : Sealey
• Nett Weight : 1.29kg
• Voltage AC : Range; 750V, Max Resolution; 1V, Accuracy; (±1.2% ± 10-digits)
• Voltage DC : Range; 1000V, Max Resolution; 1V, Accuracy; (±0.8% ± 3-digits)
• Resistance : Range; 200Ω, 2000Ω, Max Resolution; 0.1Ω, 1Ω, Accuracy; (±1% ± 2-digits)
• Insulation Resistance : Range; 200MΩ, 2000MΩ, Max Resolution; 100kΩ-1MΩ, Accuracy; (±3.5% ± 5-digits)
• Test Voltage : 250V/200MΩ, 500V/200MΩ, 1000V/2000MΩ
• Continuity Test : Active Sound Level; ≤40Ω, Test Current; ≤200mA
• Operating Temperature : 0ºC to +40ºC, (<80%R.H)
• Storage Temperature : -10ºC to +60ºC, (<70%R.H)
• Batteries : 6 x 1.5V (supplied)
